Two Hole Mechanical Lugs CLB-2K-Vy-36-3-185-400 is designed for aluminum and copper connections to a flat bar or equipment pads equipped with 2-hole spacing for low and medium voltage applications up to 36 kV, these lugs accommodate conductor cross-sections from 185 to 400 mm². They are suitable for both outdoor and indoor use, available with various palm hole sizes.
The bolted fitting is specifically developed for medium voltage cable accessories (up to 36 kV), but it can also be applied in the 1 kV range.
Technical specification
Product code
Cable size, mm2
Torque, Nm
Bolt number
Application cable
CLB-2K-Vy-36-3-185-400
185-400
48-54
3
Copper/Aluminum
Components and Materials
Mechanical shear bolt terminal lug CLB-2K-Vy-36-3-185-400 is produced by a direct factory location in China -- Jera Line, the Lug body is made of a high-tensile, tin-plated aluminium alloy. The internal surface of the conductor holes are grooved.
Components
Materials
Body
Aluminum alloy, tin covered
Shear off torque bolts
Aluminum alloy
Dimensions
Test
Jera Line 2-hole terminal lug CLB-2K-Vy-36-3-185-400has passed routine test by Jera Line own factory laboratory, and provide factory test report if required.
We do the following test:
● Visual inspection test and dimensional and material verification test
● Mechanical tension test according to standard IEC 61238-1-3
● Shear head functions test according to standard IEC 61238-1-3
