Model No. :

CCBIT-4-120-300

Description:

Shear bolt cable connector, CCBIT-4-120-300 either called shear-off-head bolts connectors, were designed for connection the aluminum or copper wire to the electric circuit under voltage 1, 11kV. Cable connector shear stud applied in joints of power cable of non-insulated conductors.

  • Product detail
  • Specification
  • Video
  • Inquiry

Key Features

  1. Made of tin covered aluminum for copper and aluminum
  2. Extended application size of electrical cables
  3. Universal shape of input hole, for solid and stranded cables
  4. Rapid installation by using hex key
  5. Three zones of shearing off head bolt
  6. Differential outer diameter size for solid protection after heat shrink
  7. Inner jointing grease guarantee sustainable electrical contact
  8. Excellent electrical stability
Shear bolt cable connector, CCBIT-4-120-300 Shear bolt cable connector, CCBIT-4-120-300

SPECIFICATION

Shear Head Bolt Connectors

Product analogs: Cable connector with shear-off-head bolts

Terminal connector Shear Stud CCBIT-4-120-300 applied with aluminum and copper cables, stranded shaped, circular, and solid with cross section of cable line 120-300 mm2. Screw Type Cable Joint provides excellent environmental protection and long life time duration.

Mechanical Cable Connector CCBIT-4-120-300 is made of high strength aluminum material. The bolts may be produced from brass, according to requirement. Application area is low voltage electrical power lines, underground electrical networks, buildings.

read more

APPLICATION

Screw Type Cable Joint

Bolt cable connector and electrical cables jointing process does not require the compression tool with exact size. All required tension force is achieved by shearing off the head of bolt by hex key, which tighten the bolt. The shear bolt shears off when needed torque reached, which guarantee the stable electrical connection.

Aluminum mechanical cable connector is tin covered. Inner jointing grease guarantee sustainable electrical contact. Shear bolt cable lugs and connectors are available in our product range.

Welcome to contact our sales team to have more details about this Cable connector joint price.

read more

Manufacturing

    app

Watch Our Factory Video

Technical specification

Product code

Cable diameter, mm2

Size bolt, M/ hex size

No. of bolts

Available bolt materials

Applicable cables

CCBIT-4-120-300

120-300

24/24

4

Aluminum uncoated, tin coated, brass

Copper, Aluminum
