The PowerSafe Powerlock Connector 400A line is designed to provide safe, secure, and reliable low-voltage power connections in high-current industrial and commercial power distribution systems. With its robust locking mechanism and advanced safety features, it ensures uninterrupted power delivery in critical applications.
The PowerSafe Powerlock Connector is widely used in:
• Industrial power distribution systems requiring high-current, secure connections
• Data centers and critical infrastructure, supporting continuous and stable power supply
• Temporary and mobile power installations, including generators and rental power equipment
• UPS and backup power systems for safe power transfer and load management
• Renewable energy and energy storage systems, such as battery and inverter connections
• Construction sites, events, and outdoor installations demanding rugged and reliable power solutions
Technical specification
Model
Color
Capacity
Voltage
Operating temperature
Size of Strand head
Docking dust proof level
EU Standard 400A Socket L1 – Brown (PL-L1-F-400A-EU-Z)
Brown
400A
1000V
-45-85°C
M50
IP67
EU Standard 400A Socket L2 – Black (PL-L2-F-400A-EU-H)
Black
400A
1000V
-45-85°C
M50
IP67
EU Standard 400A Socket L3 – Grey (PL-L3-F-400A-EU-H)
Grey
400A
1000V
-45-85°C
M50
IP67
EU Standard 400A Socket N – Blue (PL-N-F-400A-EU-L)
Blue
400A
1000V
-45-85°C
M50
IP67
EU Standard 400A Socket E – Green (PL-E-F-400A-EU-L)
Green
400A
1000V
-45-85°C
M50
IP67
Components and Materials
Jera Line is a Rotalock power connector manufacturer in China, these connectors Engineered with finger-safe contacts, flame-retardant materials, and secure locking engagement, the PowerSafe Powerlock Connector delivers dependable performance, enhanced safety, and long service life in demanding operating environments.
The product included the following parts:
Component
Description
Connector housing
impact resistance and flame retardant plastic
Locking Mechanism
Brass and stainless steel
Power contact
Brass (up to 400 A), silverplated
· Copper (up to 660 A), silver
plated
Material seals
Neoprene
Material springs/release pin
Austenitic steel
Material contact retaining pin
PA
Dimensions
Test
Jera Line PowerSafe powerlock connectors set for low-voltage (LV) applications are designed and tested to ensure electrical safety, mechanical reliability, and long-term performance in high-current power distribution systems. All testing is conducted in accordance with relevant international standards and strict factory quality control procedures.
