Branching connector set SV50 includes three phase connectors of KE10.504 and neutral connector of KE10.506, plus an 16mm2 earth wire of 35cm with a cable lug.
The SV50 branching connector setis designed for creating reliable low‑voltage branch connections in power distribution networks. It is suitable for both aluminium and copper conductors, making it ideal for mixed‑material LV systems used by utilities, industrial facilities, and infrastructure projects.
The SV50 set is commonly used in:
• Overhead LV distribution lines
• For branching service lines or extending existing circuits.
• Underground and cabinet‑based LV networks
• Suitable for installation inside metal poles, distribution cabinets, and junction boxes.
• Service connections to buildings and equipment
• Ensures stable and safe branching for residential, commercial, and industrial loads.
• Network upgrades and maintenance
• Provides a dependable solution for retrofitting or expanding existing LV grids.
Technical specification
Product code
3*KE10.504+1*KE10.506+wire
Ratings
ETIM class, low current connector
Colour
Transparent
Model
Branch
Tightening torque Nm
10
Highest system voltage, kV
1
Conductor size Al, mm2
10-50
Conductor size Cu, mm2
2.5-35
Core diameter, mm
2-10.2
Max. number of cores
4
Components and Materials
The SV50 branching connector set from Jera Line is engineered for dependable low‑voltage branching applications in overhead and underground distribution networks. Developed and tested in Jera Line’s in‑house laboratory, the SV50 set meets international standards and customer‑specific technical requirements, ensuring long‑term electrical stability and mechanical reliability.
Below are the main components included in the SV15 branching connector set:
Components
Materials
House
Polycarbonate
Screws
Nickel-plated brass
Connector body
Tinned aluminium
