Low voltage branching connector is also called Electrical connector for LV networks, it’s used for aluminum and copper wires, 6x (AL10-35/ Cu1.5-25)mm2
The KE 10.3 LV branching connector is designed for reliable branching of low‑voltage aluminium and copper conductors in distribution networks. Engineered for stable electrical performance and long‑term durability, it ensures secure contact and efficient power transfer in a wide range of installation environments.
Technical specification
Product code
KE10.3
Ratings
ETIM class, low current connector
Colour
Transparent
Model
Branch
Tightening torque Nm
10
Highest system voltage, kV
1
Conductor size Al, mm2
10-35
Conductor size Cu, mm2
1.5-25
Core diameter, mm
1.7-9
Max. number of cores
1
Components and Materials
KE10.3 connector for low‑voltage distribution systems is for cable connectors for low voltages. The LV branching connector were developed, tested, and manufactured under strict quality management systems, ensuring compliance with international standards as well as customer‑specific technical requirements. This guarantees consistent performance, safety, and reliability in demanding installation environments.
The Electrical branching connector consists of the following main part:
Components
Materials
House
Polycarbonate
Screws
Nickel-plated brass
Connector body
Tinned aluminium
