Power lock connector LV EU Standard 400A Plug L3 – Grey (PL-L3-M-400A-EU-H)

Power lock connector lv, flame retardant UL94-V0, IP67, EU Standard 400A, CE approved

Features

400A continuous load capacity
IP67 waterproof and dustproof protection
EU-standard color coding (Grey for L3)
IP2X safety protection
Flame-retardant (UL94-V0) materials
Mechanical locking system
Factory location in China

DESCRIPTION

TEST

REVIEW

Application

Jera Line’s Powerlock connectors for low voltage (EU Standard 400A) are designed for safe, high-current single-pole connections in industrial, utility, renewable energy, and event power distribution systems. They feature secure mechanical locking, EU-standard phase color coding, and IP-rated protection for reliable use in demanding environments.

Typical Application:

• Applied in factories, workshops, and heavy machinery

• Substations, maintenance, and construction projects

• Data centers and backup power systems

• Solar panels, wind turbines, and hydroelectric generators

• Mobile generators and backup systems

Technical specification

Model	Color	Capacity	Voltage	Operating temperature	Size of Strand head	Docking dust proof level
EU Standard 400A Plug L1 – Brown (PL-L1-M-400A-EU-Z)	Brown	400A	1000V	-45-85°C	M50	IP67
EU Standard 400A Plug L2 – Black (PL-L2-M-400A-EU-H)	Black	400A	1000V	-45-85°C	M50	IP67
EU Standard 400A Plug L3 – Grey (PL-L3-M-400A-EU-H)	Grey	400A	1000V	-45-85°C	M50	IP67
EU Standard 400A Plug N – Blue (PL-N-M-400A-EU-L)	Blue	400A	1000V	-45-85°C	M50	IP67
EU Standard 400A Plug E – Green (PL-E-M-400A-EU-L)	Green	400A	1000V	-45-85°C	M50	IP67

Components and Materials

Jera Line is a Powerlock connectors LV 1000v manufacturer in China, the industrial power locking connector combines robust polymer insulation, precision-machined copper contacts, stainless steel locking hardware, and silicone sealing to deliver safe, reliable, and durable high-current connections in industrial, utility, and event power applications.

The product included the following parts:

Component	Description
Connector housing	impact resistance and flame retardant plastic
Locking Mechanism	Brass and stainless steel
Power contact	Brass (up to 400 A), silverplated · Copper (up to 660 A), silver plated
Material seals	Neoprene
Material springs/release pin	Austenitic steel
Material contact retaining pin	PA

Dimensions

Test

Jera Line EU Standard 400A Powerlock Plug undergoes rigorous IEC-compliant testing to guarantee safe, durable, and reliable performance in industrial, utility, renewable energy, and event power distribution systems.

Jera line also has in house laboratory, which allow us to do Environmental performance validation such as UV test and temperature & humidity aging test.
