LV pre-insulated shear head bolt lugs & connectors

Jera Line offers a comprehensive range of high-quality pre-insulated lugs and connectors designed for low voltage applications up to 1kV. These connectors and lugs are critical for terminating and connecting cables in electrical systems, ensuring a secure and reliable electrical connection.

Jera Line's Comprehensive Range of Pre insulated lugs and connectors up to 1KV solution

1. Pre-insulated cable lugs, ICLP series

ICLP-435(4-35MM2)

It offers excellent protection and a secure connection for cables, suitable for indoor and outdoor applications.

2. Pre-insulated cable connector, ICCP series

Pre-insulated cable connectors for secure and reliable connections between cables.
Ideal for use in distribution boxes and junction boxes.
Includes models such as ICCP-2-435 and ICCPp-4-35-185.

3. Pre-insulated cable lugs, ICL series

Pre-insulated cable lugs for a wide range of applications, including solar power systems, wind power systems, and industrial installations.
Available in sizes from 16mm² to 400mm², suitable for both aluminum and copper cables.
Includes models such as :ICL-16-95; ICL-2-70-240; ICL-2-185-400

Installation process: YouTube video

Key features:

Insulation protection: UV resistant polymer insulation rubber, durable, it instead of heat or cold shrinks tubes, provides protection against electrical shock, waterproof and mechanical damage.
Spearhead bolts installation: Precise torque, no compression tools, the bolted design allows for easy installation and removal, making it suitable for situations where connections may need to be frequently adjusted or inspected.
Material and Conductivity: The conductive part of lug is made from tin covered Aluminum material, is suitable for both Aluminum and Copper cables applications.
Variety of sizes: The ICL series cable usage size from 16-400mm2
Standard: They are Manufactured according to the standard: EN 50483 & IEC 61238-1.

4. Pre-insulated cable lugs CPTA series (E-173 & E-215)

Pre-insulated cable lugs designed for connecting outdoor distribution networks to indoor busbars or other electrical equipment.
Suitable for cable sizes from 35-150mm².
Marked with distinct letter and rubber color codes for easy size identification.

Advantages of Jera Line Pre insulated lugs and connectors up to 1KV solution

Enhanced Safety: Pre-insulated design minimizes the risk of electrical shock and short circuits.
High-Quality Materials: Manufactured using high-quality materials for optimal performance and durability.
Easy Installation:TSimplifies the installation process, reducing labor costs and downtime.
Comprehensive Range: Suitable for a wide range of applications in low-voltage application up to 1kV.
Competitive Pricing: Jera Line is a direct factory in China with organized production process, which cause the price competitive.
Customization Options: Available to meet specific project requirements.
Compliance with Industry Standards: Our lugs and connectors are manufactured in accordance with the international industry standards.

Conclusion

By choosing Jera Line's pre-insulated lugs and connectors, you can:

Enhance the safety and reliability of your electrical systems.
Improve the efficiency of your installation processes.
Reduce maintenance costs.
Ensure long-term performance and durability.
